M5600015 Case Feet Kit 1
Scroll

M5600015

Case Feet Kit 1

Universal case feet for all types of plastic and metal enclosures with max. 0.016" (4 mm) wall thickness. Call us for a free sample.

Version

Without tilt legs.

Supply

Foot molding (x4), TPE non-slip insert (x4), self-tapping screw (x4).

Add to my basket Add to my basket Add to my basket
product added to your basket
continue or open your product basket
Generate my PDF Datasheet

Generate Your PDF Datasheet for M5600015

Please select the product details you would like to include in the PDF.

Close
  • To be used for
M4919115 VERSAMET 19" 1Ux6.49"

M4919115

VERSAMET 19" 1Ux6.49" Modern and versatile 19" rack cases with anodized front panel and integrated 'comfort-handles'. Folded aluminum case body with all fixings hidden on the underside. Removable base and rear panel for easy access.

Supply 1U x 19" front panel, two handles, top cover, base panel, rear panel, M3 x 8 mm (x6), M3 x 8 mm (x4), M4 nut and washer (x4). Supplied assembled.

Close

M4919115

VERSAMET 19" 1Ux6.49"
product added to your basket
Aluminum
Light gray RAL 7035
1.73″x19.02″x6.50″
M4919125 VERSAMET 19" 1Ux10.43"

M4919125

VERSAMET 19" 1Ux10.43" Modern and versatile 19" rack cases with anodized front panel and integrated 'comfort-handles'. Folded aluminum case body with all fixings hidden on the underside. Removable base and rear panel for easy access.

Supply 1U x 19" front panel, two handles, top cover, base panel, rear panel, M3 x 8 mm (x6), M3 x 8 mm (x6), M4 nut and washer (x4). Supplied assembled.

Close

M4919125

VERSAMET 19" 1Ux10.43"
product added to your basket
Aluminum
Light gray RAL 7035
1.73″x19.02″x10.43″
M5619225 UNIMET 19" 2Ux11.02"

M5619225

UNIMET 19" 2Ux11.02" Modern high quality 19" rack case with integrated 'comfort handles'. All aluminum design with highly attractive front bezel and fabricated case body. Removable base and rear panels for easy access. Open front panel aperture means the case does not have to be removed from the rack in order to access the electronics. Base panel is punched to accept accessory tilt feet. Order front panel separately.

Supply 19" front bezel, top cover, base panel, rear panel, M4 x 16 mm (x4), M3 x 8 mm (x6), M3 x 8 mm (x6) and M3 x 8 mm (x4). Supplied fully assembled.

Close

M5619225

UNIMET 19" 2Ux11.02"
product added to your basket
Aluminum
Light gray/window gray RAL 7035/7040
3.46″x19.00″x11.02″
M5619235 UNIMET 19" 2Ux14.96"

M5619235

UNIMET 19" 2Ux14.96" Modern high quality 19" rack case with integrated 'comfort handles'. All aluminum design with highly attractive front bezel and fabricated case body. Removable base and rear panels for easy access. Open front panel aperture means the case does not have to be removed from the rack in order to access the electronics. Base panel is punched to accept accessory tilt feet. Order front panel separately.

Supply 19" front bezel, top cover, base panel, rear panel, M4 x 16 mm (x4), M3 x 8 mm (x6), M3 x 8 mm (x6) and M3 x 8 mm (x4). Supplied fully assembled.

Close

M5619235

UNIMET 19" 2Ux14.96"
product added to your basket
Aluminum
Light gray/window gray RAL 7035/7040
3.46″x19.00″x14.96″
M5619325 UNIMET 19" 3Ux11.02"

M5619325

UNIMET 19" 3Ux11.02" Modern high quality 19" rack case with integrated 'comfort handles'. All aluminum design with highly attractive front bezel and fabricated case body. Removable base and rear panels for easy access. Open front panel aperture means the case does not have to be removed from the rack in order to access the electronics. Base panel is punched to accept accessory tilt feet. Order front panel separately.

Supply 19" front bezel, top cover, base panel, rear panel, M4 x 16 mm (x4), M3 x 8 mm (x6), M3 x 8 mm (x6) and M3 x 8 mm (x4). Supplied fully assembled.

Close

M5619325

UNIMET 19" 3Ux11.02"
product added to your basket
Aluminum
Light gray/window gray RAL 7035/7040
5.22″x19.00″x11.02″
M5619335 UNIMET 19" 3Ux14.96"

M5619335

UNIMET 19" 3Ux14.96" Modern high quality 19" rack case with integrated 'comfort handles'. All aluminum design with highly attractive front bezel and fabricated case body. Removable base and rear panels for easy access. Open front panel aperture means the case does not have to be removed from the rack in order to access the electronics. Base panel is punched to accept accessory tilt feet. Order front panel separately.

Supply 19" front bezel, top cover, base panel, rear panel, M4 x 16 mm (x4), M3 x 8 mm (x6), M3 x 8 mm (x6) and M3 x 8 mm (x4). Supplied fully assembled.

Close

M5619335

UNIMET 19" 3Ux14.96"
product added to your basket
Aluminum
Light gray/window gray RAL 7035/7040
5.22″x19.00″x14.96″
M5623005 UNIMET 1

M5623005

UNIMET 1 Modern instrument enclosure for desktop electronics. Highly attractive die cast front bezel is fitted to the fabricated case body. The base and rear panels are removable for easy access. Mounting holes in the base are designed for fitting the accessory PCB pillars. Order the front panel separately.

Version Without handle/bail arm

Supply Front bezel, top cover, base panel, rear panel, non-slip self-adhesive foot (x4), M3 x 8 mm (x8), M4 x 16 mm (x2), M3 x 8 mm (x4). Supplied assembled.

Close

M5623005

UNIMET 1
product added to your basket
Aluminum
Light gray/window gray RAL 7035/7040
9.06″x7.48″x1.97″
M5623015 UNIMET-PLUS 1

M5623015

UNIMET-PLUS 1 Advanced instrument enclosure for desktop electronics. Stylish front and rear bezels are fitted to the fabricated case body. Pre-assembled internal chassis supplied with four snap-in PCB guides. Two standard guide positions - additional positions can be punched on demand. The case is supplied with a rear panel and four non-slip feet. Order front panels separately.

Version Without handle/bail arm

Supply Front bezel (x2), top cover, base and chassis assembly, rear panel, 4 nylon PCB guides, non-slip self-adhesive foot (x4), M3 x 8 mm (x8), M4 x 16 mm (x4). Supplied assembled.

Close

M5623015

UNIMET-PLUS 1
product added to your basket
Aluminum
Light gray/window gray RAL 7035/7040
9.06″x7.60″x1.97″
M5623025 UNIMET 1H

M5623025

UNIMET 1H Modern instrument enclosure with handle/bail arm for desktop and portable electronics. Highly attractive die cast front bezel is fitted to the fabricated case body. The handle/bail arm can be indexed at 30° increments.The base and rear panels are removable for easy access. Mounting holes in the base are designed for fitting the accessory PCB pillars. Order the front panel separately.

Version With handle/bail arm

Supply Front bezel, top cover, base panel, rear panel, carry handle/bail arm kit, non-slip self-adhesive foot (x4), M3 x 8 mm (x8), M4 x 16 mm (x2), M3 x 8 mm (x4). Supplied assembled.

Close

M5623025

UNIMET 1H
product added to your basket
Aluminum
Light gray/window gray RAL 7035/7040
9.06″x7.48″x1.97″
M5623035 UNIMET-PLUS 1H

M5623035

UNIMET-PLUS 1H Advanced instrument enclosure with handle/bail arm for desktop and portable electronics. Stylish front and rear bezels are fitted to the fabricated case body. The handle can be indexed at 30° increments.Pre-assembled internal chassis supplied with four snap-in PCB guides. Four standard guide positions - additional positions can be punched on demand. The case is supplied with a rear panel and four non-slip feet. Order front panels separately.

Version With handle/bail arm

Supply Front bezel (x2), top cover, base and chassis assembly, rear panel, 4 nylon PCB guides, carry handle/bail arm kit, non-slip self-adhesive foot (x4), M3 x 8 mm (x8), M4 x 16 mm (x4). Supplied assembled.

Close

M5623035

UNIMET-PLUS 1H
product added to your basket
Aluminum
Light gray/window gray RAL 7035/7040
9.06″x7.60″x1.97″
M5623105 UNIMET 2

M5623105

UNIMET 2 Modern instrument enclosure for desktop electronics. Highly attractive die cast front bezel is fitted to the fabricated case body. The base and rear panels are removable for easy access. Mounting holes in the base are designed for fitting the accessory PCB pillars. Order the front panel separately.

Version Without handle/bail arm

Supply Front bezel, top cover, base panel, rear panel, non-slip self-adhesive foot (x4), M3 x 8 mm (x8), M4 x 16 mm (x4), M3 x 8 mm (x4). Supplied assembled.

Close

M5623105

UNIMET 2
product added to your basket
Aluminum
Light gray/window gray RAL 7035/7040
9.06″x7.48″x3.35″
M5623115 UNIMET-PLUS 2

M5623115

UNIMET-PLUS 2 Advanced instrument enclosure for desktop electronics. Stylish front and rear bezels are fitted to the fabricated case body. Pre-assembled internal chassis supplied with four snap-in PCB guides. Four standard guide positions - additional positions can be punched on demand. The case is supplied with a rear panel and four non-slip feet. Order front panels separately.

Version Without handle/bail arm

Supply Front bezel (x2), top cover, base and chassis assembly, rear panel, 4 nylon PCB guides, non-slip self-adhesive foot (x4), M3 x 8 mm (x8), M4 x 16 mm (x8). Supplied assembled.

Close

M5623115

UNIMET-PLUS 2
product added to your basket
Aluminum
Light gray/window gray RAL 7035/7040
9.06″x7.60″x3.35″
M5623125 UNIMET 2H

M5623125

UNIMET 2H Modern instrument enclosure with handle/bail arm for desktop and portable electronics. Highly attractive die cast front bezel is fitted to the fabricated case body. The handle/bail arm can be indexed at 30° increments.The base and rear panels are removable for easy access. Mounting holes in the base are designed for fitting the accessory PCB pillars. Order the front panel separately.

Version With handle/bail arm

Supply Front bezel, top cover, base panel, rear panel, carry handle/bail arm kit, non-slip self-adhesive foot (x4), M3 x 8 mm (x8), M4 x 16 mm (x2), M3 x 8 mm (x4). Supplied assembled.

Close

M5623125

UNIMET 2H
product added to your basket
Aluminum
Light gray/window gray RAL 7035/7040
9.06″x7.48″x3.35″
M5623135 UNIMET-PLUS 2H

M5623135

UNIMET-PLUS 2H Advanced instrument enclosure with handle/bail arm for desktop and portable electronics. Stylish front and rear bezels are fitted to the fabricated case body. The handle can be indexed at 30° increments.Pre-assembled internal chassis supplied with four snap-in PCB guides. Four standard guide positions - additional positions can be punched on demand. The case is supplied with a rear panel and four non-slip feet. Order front panels separately.

Version With handle/bail arm

Supply Front bezel (x2), top cover, base and chassis assembly, rear panel, 4 nylon PCB guides, carry handle/bail arm kit, non-slip self-adhesive foot (x4), M3 x 8 mm (x8), M4 x 16 mm (x8). Supplied assembled.

Close

M5623135

UNIMET-PLUS 2H
product added to your basket
Aluminum
Light gray/window gray RAL 7035/7040
9.06″x7.60″x3.35″
M5625105 UNIMET 3

M5625105

UNIMET 3 Modern instrument enclosure for desktop electronics. Highly attractive die cast front bezel is fitted to the fabricated case body. The base and rear panels are removable for easy access. Mounting holes in the base are designed for fitting the accessory PCB pillars. Order the front panel separately.

Version Without handle/bail arm

Supply Front bezel, top cover, base panel, rear panel, non-slip self-adhesive foot (x4), M3 x 8 mm (x8), M4 x 16 mm (x4), M3 x 8 mm (x4). Supplied assembled.

Close

M5625105

UNIMET 3
product added to your basket
Aluminum
Light gray/window gray RAL 7035/7040
9.84″x10.24″x3.35″
M5625115 UNIMET-PLUS 3

M5625115

UNIMET-PLUS 3 Advanced instrument enclosure for desktop electronics. Stylish front and rear bezels are fitted to the fabricated case body. Pre-assembled internal chassis supplied with four snap-in PCB guides. Four standard guide positions - additional positions can be punched on demand. The case is supplied with a rear panel and four non-slip feet. Order front panels separately.

Version Without handle/bail arm

Supply Front bezel (x2), top cover, base and chassis assembly, rear panel, 4 nylon PCB guides, non-slip self-adhesive foot (x4), M3 x 8 mm (x8), M4 x 16 mm (x8). Supplied assembled.

Close

M5625115

UNIMET-PLUS 3
product added to your basket
Aluminum
Light gray/window gray RAL 7035/7040
9.84″x10.35″x3.35″
M5625125 UNIMET 3H

M5625125

UNIMET 3H Modern instrument enclosure with handle/bail arm for desktop and portable electronics. Highly attractive die cast front bezel is fitted to the fabricated case body. The handle/bail arm can be indexed at 30° increments.The base and rear panels are removable for easy access. Mounting holes in the base are designed for fitting the accessory PCB pillars. Order the front panel separately.

Version With handle/bail arm

Supply Front bezel, top cover, base panel, rear panel, carry handle/bail arm kit, non-slip self-adhesive foot (x4), M3 x 8 mm (x8), M4 x 16 mm (x2), M3 x 8 mm (x4). Supplied assembled.

Close

M5625125

UNIMET 3H
product added to your basket
Aluminum
Light gray/window gray RAL 7035/7040
9.84″x10.24″x3.35″
M5625135 UNIMET-PLUS 3H

M5625135

UNIMET-PLUS 3H Advanced instrument enclosure with handle/bail arm for desktop and portable electronics. Stylish front and rear bezels are fitted to the fabricated case body. The handle can be indexed at 30° increments.Pre-assembled internal chassis supplied with four snap-in PCB guides. Four standard guide positions - additional positions can be punched on demand. The case is supplied with a rear panel and four non-slip feet. Order front panels separately.

Version With handle/bail arm

Supply Front bezel (x2), top cover, base and chassis assembly, rear panel, 4 nylon PCB guides, carry handle/bail arm kit, non-slip self-adhesive foot (x4), M3 x 8 mm (x8), M4 x 16 mm (x8). Supplied assembled.

Close

M5625135

UNIMET-PLUS 3H
product added to your basket
Aluminum
Light gray/window gray RAL 7035/7040
9.84″x10.35″x3.35″
M5625305 UNIMET 5

M5625305

UNIMET 5 Modern instrument enclosure for desktop electronics. Highly attractive die cast front bezel is fitted to the fabricated case body. The base and rear panels are removable for easy access. Mounting holes in the base are designed for fitting the accessory PCB pillars. Order the front panel separately.

Version Without handle/bail arm

Supply Front bezel, top cover, base panel, rear panel, non-slip self-adhesive foot (x4), M3 x 8 mm (x8), M4 x 16 mm (x4), M3 x 8 mm (x4). Supplied assembled.

Close

M5625305

UNIMET 5
product added to your basket
Aluminum
Light gray/window gray RAL 7035/7040
9.84″x10.24″x5.91″
M5625315 UNIMET-PLUS 5

M5625315

UNIMET-PLUS 5 Advanced instrument enclosure for desktop electronics. Stylish front and rear bezels are fitted to the fabricated case body. Pre-assembled internal chassis supplied with four snap-in PCB guides. Four standard guide positions - additional positions can be punched on demand. The case is supplied with a rear panel and four non-slip feet. Order front panels separately.

Version Without handle/bail arm

Supply Front bezel (x2), top cover, base and chassis assembly, rear panel, 4 nylon PCB guides, non-slip self-adhesive foot (x4), M3 x 8 mm (x8), M4 x 16 mm (x8). Supplied assembled.

Close

M5625315

UNIMET-PLUS 5
product added to your basket
Aluminum
Light gray/window gray RAL 7035/7040
9.84″x10.35″x5.91″
M5625325 UNIMET 5H

M5625325

UNIMET 5H Modern instrument enclosure with handle/bail arm for desktop and portable electronics. Highly attractive die cast front bezel is fitted to the fabricated case body. The handle/bail arm can be indexed at 30° increments.The base and rear panels are removable for easy access. Mounting holes in the base are designed for fitting the accessory PCB pillars. Order the front panel separately.

Version With handle/bail arm

Supply Front bezel, top cover, base panel, rear panel, carry handle/bail arm kit, non-slip self-adhesive foot (x4), M3 x 8 mm (x8), M4 x 16 mm (x2), M3 x 8 mm (x4). Supplied assembled.

Close

M5625325

UNIMET 5H
product added to your basket
Aluminum
Light gray/window gray RAL 7035/7040
9.84″x10.24″x5.91″
M5625335 UNIMET-PLUS 5H

M5625335

UNIMET-PLUS 5H Advanced instrument enclosure with handle/bail arm for desktop and portable electronics. Stylish front and rear bezels are fitted to the fabricated case body. The handle can be indexed at 30° increments.Pre-assembled internal chassis supplied with four snap-in PCB guides. Four standard guide positions - additional positions can be punched on demand. The case is supplied with a rear panel and four non-slip feet. Order front panels separately.

Version With handle/bail arm

Supply Front bezel (x2), top cover, base and chassis assembly, rear panel, 4 nylon PCB guides, carry handle/bail arm kit, non-slip self-adhesive foot (x4), M3 x 8 mm (x8), M4 x 16 mm (x8). Supplied assembled.

Close

M5625335

UNIMET-PLUS 5H
product added to your basket
Aluminum
Light gray/window gray RAL 7035/7040
9.84″x10.35″x5.91″
M5635205 UNIMET 4

M5635205

UNIMET 4 Modern instrument enclosure for desktop electronics. Highly attractive die cast front bezel is fitted to the fabricated case body. The base and rear panels are removable for easy access. Mounting holes in the base are designed for fitting the accessory PCB pillars. Order the front panel separately.

Version Without handle/bail arm

Supply Front bezel, top cover, base panel, rear panel, non-slip self-adhesive foot (x4), M3 x 8 mm (x8), M4 x 16 mm (x4), M3 x 8 mm (x4). Supplied assembled.

Close

M5635205

UNIMET 4
product added to your basket
Aluminum
Light gray/window gray RAL 7035/7040
13.78″x10.24″x4.72″
M5635215 UNIMET-PLUS 4

M5635215

UNIMET-PLUS 4 Advanced instrument enclosure for desktop electronics. Stylish front and rear bezels are fitted to the fabricated case body. Pre-assembled internal chassis supplied with four snap-in PCB guides. Four standard guide positions - additional positions can be punched on demand. The case is supplied with a rear panel and four non-slip feet. Order front panels separately.

Version Without handle/bail arm

Supply Front bezel (x2), top cover, base and chassis assembly, rear panel, 4 nylon PCB guides, non-slip self-adhesive foot (x4), M3 x 8 mm (x8), M4 x 16 mm (x8). Supplied assembled.

Close

M5635215

UNIMET-PLUS 4
product added to your basket
Aluminum
Light gray/window gray RAL 7035/7040
13.78″x10.35″x4.72″
M5635225 UNIMET 4H

M5635225

UNIMET 4H Modern instrument enclosure with handle/bail arm for desktop and portable electronics. Highly attractive die cast front bezel is fitted to the fabricated case body. The handle/bail arm can be indexed at 30° increments.The base and rear panels are removable for easy access. Mounting holes in the base are designed for fitting the accessory PCB pillars. Order the front panel separately.

Version With handle/bail arm

Supply Front bezel, top cover, base panel, rear panel, carry handle/bail arm kit, non-slip self-adhesive foot (x4), M3 x 8 mm (x8), M4 x 16 mm (x2), M3 x 8 mm (x4). Supplied assembled.

Close

M5635225

UNIMET 4H
product added to your basket
Aluminum
Light gray/window gray RAL 7035/7040
13.78″x10.24″x4.72″
M5635235 UNIMET-PLUS 4H

M5635235

UNIMET-PLUS 4H Advanced instrument enclosure with handle/bail arm for desktop and portable electronics. Stylish front and rear bezels are fitted to the fabricated case body. The handle can be indexed at 30° increments.Pre-assembled internal chassis supplied with four snap-in PCB guides. Four standard guide positions - additional positions can be punched on demand. The case is supplied with a rear panel and four non-slip feet. Order front panels separately.

Version With handle/bail arm

Supply Front bezel (x2), top cover, base and chassis assembly, rear panel, 4 nylon PCB guides, carry handle/bail arm kit, non-slip self-adhesive foot (x4), M3 x 8 mm (x8), M4 x 16 mm (x8). Supplied assembled.

Close

M5635235

UNIMET-PLUS 4H
product added to your basket
Aluminum
Light gray/window gray RAL 7035/7040
13.78″x10.35″x4.72″
M5635305 UNIMET 6

M5635305

UNIMET 6 Modern instrument enclosure for desktop electronics. Highly attractive die cast front bezel is fitted to the fabricated case body. The base and rear panels are removable for easy access. Mounting holes in base are designed for fitting the accessory PCB pillars. Order the front panel separately.

Version Without handle/bail arm

Supply Front bezel, top cover, base panel, rear panel, non-slip self-adhesive foot (x4), M3 x 8 mm (x8), M4 x 16 mm (x4), M3 x 8 mm (x4). Supplied assembled.

Close

M5635305

UNIMET 6
product added to your basket
Aluminum
Light gray/window gray RAL 7035/7040
13.78″x10.24″x5.91″
M5635315 UNIMET-PLUS 6

M5635315

UNIMET-PLUS 6 Advanced instrument enclosure for desktop electronics. Stylish front and rear bezels are fitted to the fabricated case body. Pre-assembled internal chassis supplied with four snap-in PCB guides. Four standard guide positions - additional positions can be punched on demand. The case is supplied with a rear panel and four non-slip feet. Order front panels separately.

Version Without handle/bail arm

Supply Front bezel (x2), top cover, base and chassis assembly, rear panel, 4 nylon PCB guides, non-slip self-adhesive foot (x4), M3 x 8 mm (x8), M4 x 16 mm (x8). Supplied assembled.

Close

M5635315

UNIMET-PLUS 6
product added to your basket
Aluminum
Light gray/window gray RAL 7035/7040
13.78″x10.35″x5.91″
M5635325 UNIMET 6H

M5635325

UNIMET 6H Modern instrument enclosure with handle/bail arm for desktop and portable electronics. Highly attractive die cast front bezel is fitted to the fabricated case body. The handle/bail arm can be indexed at 30° increments.The base and rear panels are removable for easy access. Mounting holes in the base are designed for fitting the accessory PCB pillars. Order the front panel separately.

Version With handle/bail arm

Supply Front bezel, top cover, base panel, rear panel, carry handle/bail arm kit, non-slip self-adhesive foot (x4), M3 x 8 mm (x8), M4 x 16 mm (x2), M3 x 8 mm (x4). Supplied assembled.

Close

M5635325

UNIMET 6H
product added to your basket
Aluminum
Light gray/window gray RAL 7035/7040
13.78″x10.24″x5.91″
M5635335 UNIMET-PLUS 6H

M5635335

UNIMET-PLUS 6H Advanced instrument enclosure with handle/bail arm for desktop and portable electronics. Stylish front and rear bezels are fitted to the fabricated case body. The handle can be indexed at 30° increments.Pre-assembled internal chassis supplied with four snap-in PCB guides. Four standard guide positions - additional positions can be punched on demand. The case is supplied with a rear panel and four non-slip feet. Order front panels separately.

Version With handle/bail arm

Supply Front bezel (x2), top cover, base and chassis assembly, rear panel, 4 nylon PCB guides, carry handle/bail arm kit, non-slip self-adhesive foot (x4), M3 x 8 mm (x8), M4 x 16 mm (x8). Supplied assembled.

Close

M5635335

UNIMET-PLUS 6H
product added to your basket
Aluminum
Light gray/window gray RAL 7035/7040
13.78″x10.35″x5.91″
  • Technical Data
  • Drawings / Info
  • Purchasing Data
Material
ABS (UL 94 HB)
Color
Light gray RAL 7035
Standards
REACH compliant
RoHS compliant
Length
1.339″
34 mm
Width
0.669″
17 mm
Height
0.630″
16 mm

Catalog Pages

3D Models

Weight/1 part
0.02 kg
Customs tariff number
(METCASE product)
39269097
Country of manufacture
U.K.
