M5600049 Case Feet Kit 2
Scroll

M5600049

Case Feet Kit 2

Universal case feet with tilt legs for all types of plastic and metal enclosures with max. 0.016" (4 mm) wall thickness.

Tilt legs:
F Max. 200 N (TÜV SÜD tested: ASTM D642-00 - compression test)
Topple load 3.69 kg (TÜV SÜD tested: DEF STAN 00-35 Part 4 Issue 3 - topple test)

Call us for a free sample.

Version

With tilt legs.

Supply

Foot molding (x4), tilt leg (x2), TPE non-slip insert (x4), self-tapping screw (x4).

Add to my basket Add to my basket Add to my basket
product added to your basket
continue or open your product basket
Generate my PDF Datasheet

Generate Your PDF Datasheet for M5600049

Please select the product details you would like to include in the PDF.

Close
  • To be used for
M4919119 VERSAMET 19" 1Ux6.49"

M4919119

VERSAMET 19" 1Ux6.49" Modern and versatile 19" rack cases with anodized front panel and integrated 'comfort-handles'. Folded aluminum case body with all fixings hidden on the underside. Removable base and rear panel for easy access.

Supply 1U x 19" front panel, two handles, top cover, base panel, rear panel, M3 x 8 mm (x6), M3 x 8 mm (x4), M4 nut and washer (x4). Supplied assembled.

Close

M4919119

VERSAMET 19" 1Ux6.49"
product added to your basket
Aluminum
Black RAL 9005
1.73″x19.02″x6.50″
M4919129 VERSAMET 19" 1Ux10.43"

M4919129

VERSAMET 19" 1Ux10.43" Modern and versatile 19" rack cases with anodized front panel and integrated 'comfort-handles'. Folded aluminum case body with all fixings hidden on the underside. Removable base and rear panel for easy access.

Supply 1U x 19" front panel, two handles, top cover, base panel, rear panel, M3 x 8 mm (x6), M3 x 8 mm (x6), M4 nut and washer (x4). Supplied assembled.

Close

M4919129

VERSAMET 19" 1Ux10.43"
product added to your basket
Aluminum
Black RAL 9005
1.73″x19.02″x10.43″
  • Technical Data
  • Drawings / Info
  • Purchasing Data
Material
ABS (UL 94 HB)
ABS (Tilt leg) (UL 94 HB)
Color
Black RAL 9005
Standards
REACH compliant
RoHS compliant
Length
1.339″
34 mm
Width
0.669″
17 mm
Height
0.630″
16 mm

Catalog Pages

3D Models

Weight/1 part
0.04 kg
Customs tariff number
(METCASE product)
39269097
Country of manufacture
U.K.
